PLC Splitter 1:16 LC/UPC – High-Performance Optical Signal Distribution

The PLC Splitter 1:16 LC/UPC from Attac is a precision fibre optic splitter designed for balanced, efficient signal distribution in FTTH, PON, and GPON networks. Using advanced Planar Lightwave Circuit (PLC) technology, this splitter evenly divides a single input signal into 16 output channels while maintaining signal quality, stability, and low insertion loss.

Key Features

• 1:16 Split Ratio: Distributes one optical input into 16 uniform outputs
• Connectorised: Pre-terminated with LC/UPC connectors for quick plug-and-play use
• Wavelength Range: 1260–1650nm wideband operation
• Low Insertion Loss: Stable power output across all channels
• Low Polarisation Dependent Loss (PDL): Consistent performance across all conditions
• High Return Loss: UPC connectors ensure minimal signal reflection
• Standards Compliance: Built to IEC and Telcordia GR-1209/1221 standards
• Mounting: Suitable for use in ODFs, rack-mount patch panels, and fibre distribution boxes

Engineered for FTTH and PON Fibre Networks

This PLC splitter 1:16 LC/UPC is ideal for last-mile fibre connections in homes, buildings, and commercial sites. It simplifies the branching of a single incoming fibre signal to serve multiple subscribers or access points, particularly in passive optical network (PON) environments.

Pre-Terminated for Plug-and-Play Use

Save time on installations with factory pre-terminated LC/UPC connectors. These connectors offer superior mating precision, low insertion loss, and minimal signal return. Designed for high-density deployments, this splitter integrates easily into rack or wall-mount enclosures without the need for field polishing or fusion splicing.

Applications

• FTTH (Fibre-to-the-Home)
• GPON and EPON deployments
• Local Area Networks (LAN)
• Optical Distribution Frames (ODFs)
• Rack-mount fibre panels and termination boxes

Technical Specifications

• Split Ratio: 1:16
• Connector Type: LC/UPC
• Fibre Type: Singlemode (ITU-T G.657A1)
• Wavelength Range: 1260–1650nm
• Typical Insertion Loss: ≤13.5dB
• Return Loss: ≥55dB
• Operating Temp: -40°C to +85°C
• Storage Temp: -40°C to +85°C
• Compliance: IEC, Telcordia GR-1209/1221

Explore Related Fibre Products

Looking for a secure mount? Pair this splitter with our Fibre Patch Panels for a professional finish.

More Info on PLC Splitters

See this article on PLC splitters to better understand how they function in passive networks.
